Kyosho Optima 30617 1/10 4WD Electric Racing Buggy Kit
Kyosho Optima 30617 1/10 4WD Electric Racing Buggy Kit
Build the Kyosho Optima, a re-creation of the electric off-road buggy first released in 1985. This 1/10 4WD kit retains the distinctive Optima styling and narrow backbone chassis while updating the drivetrain and suspension for modern power sources. A choice of chain or belt drive, long-travel double-wishbone suspension and a slipper clutch provide setup options for off-road driving. Assembly and separately purchased radio equipment, motor, ESC and battery are required.
Key Features
- Narrow backbone chassis supports suspension geometry with large steering angles.
- Double-wishbone suspension with a long 35mm suspension stroke.
- Original-style 4WD chain system housed in a sealed compartment.
- Choice of chain-drive or belt-drive configuration.
- Robust metal counter-gear pinion and rear differential case strengthen the drivetrain.
- Slipper clutch helps protect the drivetrain under load.
- Precision 48-pitch gearing reduces drive loss and accommodates modern power sources.
- Front and rear big-bore shocks recreated in the original Optima colours.
- Hex-head screws support secure assembly.
Specifications
| Brand | Kyosho |
|---|---|
| Model / part number | Optima / 30617 (KYO-30617) |
| Scale | 1/10 |
| Drive / power | 4WD / electric |
| Drive-system options | Chain or belt drive |
| Assembly | Kit, assembly required |
| Length | 395mm |
| Width | 240mm |
| Height | 120mm |
| Ground clearance | 36mm |
| Wheelbase | 260mm |
| Track width (front / rear) | 204mm / 204mm |
| Tyre size (front / rear) | 86mm diameter × 40mm width |
| Gear ratio | 9.24:1 |
| Gear pitch | 48-pitch |
| Weight | Approximately 1,600g |
| Suspension | Double wishbone, 35mm stroke |
| Motor | 540 class, required separately |
| Battery | Standard-size 7.2V NiMH or 7.4V LiPo, required separately |
| Radio requirements | Two-channel system, one servo and one ESC |
Package Includes
- Kyosho Optima 30617 buggy kit
Required to Run (Sold Separately)
- Two-channel transmitter and receiver
- One steering servo
- One ESC compatible with the selected motor and battery
- 540-size motor
- Standard-size 7.2V NiMH or 7.4V LiPo battery
- Compatible battery charger; a regulated 12V power supply is required for a DC charger
- Body-painting supplies and tools
- Transmitter batteries
- Large and small Phillips screwdrivers, needle-nose pliers, scissors and a sharp hobby knife
